High-Efficiency Automatic Laminating Machine for Corrugated Cardboard – CH Series
The CH series automatic laminating machine is engineered for precision, speed, and reliability in producing high-quality corrugated cardboard laminates. Designed to meet industrial demands across packaging, logistics, and manufacturing sectors, this machine excels in handling surface papers ranging from 150 to 600 g/m² while seamlessly bonding them to various flute types of corrugated board. With advanced control systems, intelligent feeding mechanisms, and ergonomic design, it delivers consistent performance even under continuous operation—ideal for global manufacturers seeking efficient, low-waste laminating solutions.
Key Features:
- ✔ Vacuum suction feed system ensures accurate paper alignment and uninterrupted stacking for maximum throughput
- ✔ Servo motor-driven PLC-controlled operation with touch-screen interface for precise speed regulation and diagnostics
- ✔ Dual-frequency drive system enhances stability and reduces mechanical wear during high-speed processing
- ✔ Automatic glue circulation minimizes waste and maintains consistent adhesive application
- ✔ Floating pressure conveyor with 28 rollers ensures uniform pressure distribution across the entire laminating zone
- ✔ Scientifically designed roller line-speed control prevents glue splatter at elevated speeds
- ✔ Self-cleaning bottom roller mechanism using rubber pressure rollers keeps the reverse side of the paper clean
- ✔ Optional small (2.5m) or standard (5m) pressure table for flexible production setups
- ✔ Counter system records total sheets processed for productivity tracking and maintenance scheduling
Detailed Description:
This industrial-grade laminator supports a wide range of laminating applications—from single-face to double-faced corrugated boards—using A/B/C/E flute configurations and up to five layers. The machine accommodates minimum sheet sizes as small as 400 x 400 mm and maximum dimensions up to 1800 x 1400 mm, making it adaptable for custom packaging needs. Its economic operating speed ranges from 0 to 100 sheets per minute, ensuring optimal throughput without compromising quality. The ±1.5mm laminating accuracy guarantees tight registration between surface paper and core corrugated material, eliminating misalignment issues common in manual or semi-automated processes.
Equipped with a robust 10–12 kW power system, the CH series units are built for durability and energy efficiency. The modular structure allows easy access to cleaning tanks via gear-and-chain lifting mechanisms, simplifying maintenance routines. Additionally, the inclusion of an automatic failure alarm system helps reduce downtime by alerting operators to potential issues before they escalate into major breakdowns.
Applications:
Primarily used in corrugated box manufacturing plants, this laminator is ideal for companies producing shipping containers, display boxes, and branded packaging materials. It's also suitable for industries requiring durable, moisture-resistant laminated products such as food packaging, electronics protection, and retail product carriers. Whether you're running medium-volume production or scaling up to full automation, the CH series adapts effortlessly to your workflow.
User Feedback:
Operators worldwide praise the machine’s ease of setup, minimal operator training required, and consistent output quality. Many highlight how the vacuum-fed system eliminates paper jams and improves yield compared to older models. Users report a noticeable reduction in glue usage due to the closed-loop recycling system, translating into cost savings over time. Maintenance staff appreciate the accessible tank design and self-cleaning features that reduce labor intensity and improve hygiene standards in production environments.
Frequently Asked Questions:
What types of paper can be laminated? This machine handles surface papers from 150 to 600 g/m², including kraft paper, coated paper, and specialty finishes. It’s compatible with B-flute, C-flute, E-flute, and multi-layered corrugated cores.
Is the machine suitable for continuous operation? Yes, its servo-driven controls and dual-frequency motor system allow for reliable non-stop performance, even during extended production runs.
How does it prevent glue overspray? The scientifically calibrated roller line speed adjusts automatically based on machine speed, minimizing air turbulence and preventing glue mist formation at high velocities.
Can I customize the pressure table length? Absolutely—the optional 2.5-meter small table offers space-saving benefits, while the standard 5-meter version provides better support for longer sheets and heavier loads.
Does it integrate with existing production lines? Yes, the machine can be easily integrated into automated packaging lines thanks to its standardized input/output interfaces and programmable logic controller (PLC) compatibility.
Product Categories : Flute Laminator Machine
