Semi Automatic Gluing Machine
  • Semi Automatic Gluing Machine
  • Semi Automatic Gluing Machine
  • Semi Automatic Gluing Machine
  • Semi Automatic Gluing Machine

Semi Automatic Gluing Machine

  • $5000
    1-1
    Others
  • $4800
    2-2
    Others
  • $4500
    ≥3
    Others
Min. Order:
1 set
Transportation:
Ocean
Port:
tianjin
Share:
  • Product Description
< >
Overview
Product Attributes

Model No.: 2000

Brand: Canghai

Warranty Period: 1 Year

Applicable Industry: Manufacturing Plant

Out-of-warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service

Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): Egypt, Turkey, Indonesia, India, Mexico, Russia, Chile, Algeria, Romania

Showroom Location (in Which Countries Are There Sample Rooms Overseas): Egypt, Turkey, India, Mexico, Romania

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: New Product 2020

Core Component Warranty Period: 1 Year

Core Components: Plc, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear, Pump

Status: New

Application: Machinery &Amp; Hardware

Type Of Packaging: Film

Packaging Materials: Plastic

Degree Of Automation: Semi-Automatic

Power Type: Electric

Place Of Origin: China

Service System: Free Spare Parts

Core Selling Point: Easy To Operate

Warranty: 1 Year

Type: Other

Applicable Industries: Manufacturing Plant

Showroom Location: Pakistan, India, Mexico, Argentina, Chile, Romania, Malaysia

Video Outgoing-inspection: Provided

Machinery Test Report: Provided

Warranty Of Core Components: 1 Year

Weight: 1300 KG, 1300

Key Selling Points: Easy To Operate

Power: 3KW

Voltage: 380V

Advantage: Economical

Speed: 60pcs

Feature: Easy Work

Model Number: 2000mm

Certification: CE

Supply Ability & Additional Information

Packaging: standard packaging

Transportation: Ocean

Place of Origin: Hebei

Supply Ability: 5 set/ 30 days

Port: tianjin

Packaging & Delivery
Selling Units:
set
Package Type:
standard packaging


I. Function, feature and parameter

RS pressing type glue machine is developed for customer’ need, occupies little space

Easy to operate without skill: the machine is good at producing small order, and changing the order.

Widely be used: common box, abnormal color box which is one piece board to a box, if the machine be add auto spraying glue device, the machine also can glue Hook bottom box and four corner box

Saving material：the material only be 1/3 of manual gluing

Saving workers: the max machine speed is 56m/min, 3-4times of manual gluing

Firm gluing, tidy without spilling material: the double grinding gear can grind connect point to clear UV film or other plastic to enhance the glue material power, and solving the glue tackless in some time.

The machine with receiving box by hand, it can improve working speed and suitable for work like creasing not accurate , unnormal shape box, and some box with window which are not easy glue by automatic machine .

Parameterparameter

size

2500

power supply

3-380VAC

HZ

50/60

power

3.2KW

electric current

6.3A

weight

1.9T

max. glue size

2500mm*1100mm

min. glue size

200mm*260mm

II. Installment

After the machine arrive yours ,please pay attention to the flowing work:

1.Check if it is the machine you ordered.

2.Check if all the tools and spare parts are same as packing list.

3.Check if the machine are be good, that is to say not damaged when transport.

4.If there is any problem, please contact us.

5.Please pay attention to the machine when unload and move machine, please to avoid strong impact and shock, or it will effect machine use life and precision.

6.Please check the machine station as the install drawing



Company Profile
FAQ
1. Are you a trading company or factory? We are the manufacturer and also we have import export license. We have been making automatic high speed water based printing slotting Die Cutting Machine for more than 25 years.
2. Where is your company located? How can I visit there? Our factory address: dongguang county, Cangzhou city, hebei province,China. You could go to tianjin airport fist, and then take high speed rail come to cangzhou, we will pick you up. 3. Can you send technician for installation and training? Yes, we can send our technician abroad for installation and training, but all the charges must be paid by buyer, such as the plane tickets (a round trip), meals, hotel, traffic etc. 4. What’s your advantages ? --25 years' experience: We have been in making die cutting machine carton box for 25 years. --After-sale service: We have an aftersales department, service for your problems and dealing with spare parts. 5. Whats your guaranty time? We can take 3 years warranty, actually our longest cooperation customer have been using our product for more than 10 years with no problem.
